Aerogel is a synthetic porous ultralight material derived from a gel, in which the liquid component for the gel has been replaced with a gas. The result is a solid with extremely low density and low thermal conductivity. Nicknames include frozen smoke, solid smoke, solid air, solid cloud, blue smoke owing to its translucent nature and the way light scatters in the material.
Aerogels are a diverse class of porous, solid materials that exhibit an uncanny array of extreme materials properties. Most notably aerogels are known for their extremely low densities (which range from 0.0011 to ~0.5 g cm-3). In fact, the lowest density solid materials that have ever been produced are all aerogels, including a silica aerogel that as produced was only three times heavier than air, and could be made lighter than air by evacuating the air out of its pores.
An aerogel is the intact, dry, ultralow density, porous solid framework of a gel (that is, the part that gives a gel its solid-like cohesiveness) isolated from the gel’s liquid component (which takes up most of the volume in the gel).
The term aerogel does not refer to a particular substance, but rather to a geometry which a substance can take on–the same way a sculpture can be made out of clay, plastic, paper-mâché, etc.
Aerogels can be made of a wide variety of substances, including: silica, Most of the transition metal oxides (for example, iron oxide), Most of the lanthanide and actinide metal oxides (for example, praseodymium oxide), Several main group metal oxides (for example, tin oxide), Organic polymers (such as resorcinol-formaldehyde, phenol-formaldehyde, polyacrylates, polystyrenes, polyurethanes, and epoxies), Biological polymers (such as gelatin, pectin, and agar agar), Semiconductor nanostructures (such as cadmium selenide quantum dots), Carbon, Carbon nanotubes, Metals (such as copper and gold).
Many aerogels boast a combination of impressive materials properties that no other materials possess simultaneously. Specific formulations of aerogels hold records for the lowest bulk density of any known material (as low as 0.0011 g cm-3), the lowest mean free path of diffusion of any solid material, the highest specific surface area of any monolithic (non-powder) material (up to 3200 m2 g-1), the lowest dielectric constant of any solid material, and the slowest speed of sound through any solid material. It is important to note that not all aerogels have record properties.
By tailoring the production process, many of the properties of an aerogel can be adjusted. Bulk density is a good example of this, adjusted simply by making a more or less concentrated precursor gel. The thermal conductivity of an aerogel can be also be adjusted this way since thermal conductivity is related to density.
Typically, aerogels exhibit bulk densities ranging from 0.5 to 0.01 g cm-3 and surface areas ranging from 100 to 1000 m2 g-1, depending of course on the composition of the aerogel and the density of the precursor gel used to make the aerogel. Other properties such as transparency, colour, mechanical strength and susceptibility to water depend primarily on the composition of the aerogel.
For example, silica aerogels, which are the most widely researched type of aerogel, are usually transparent with a characteristic blue cast due to Rayleigh scattering of the short wavelengths of light off of nanoparticles that make up the aerogel’s framework. Carbon aerogels, on the other hand, are totally opaque and black. Furthermore, iron oxide aerogels are just barely translucent and can be either rust-coloured or yellow.
As another example, low-density (<0.1 g cm-3) inorganic aerogels are both excellent thermal insulators and excellent dielectric materials (electrical insulators), whereas most carbon aerogels are both good thermal insulators and electrical conductors. Thus it can be seen that by adjusting processing parameters and exploring new compositions, we can make materials with a versatile range of properties and abilities.
Its unique properties have made aerogel popular with a range of industries. Silicon manufacturers, homebuilding materials manufacturers and space agencies have all put aerogel to use. Its popularity has only been hindered by cost, though there is an increasingly successful push to create aerogels that are cost-efficient. In the meantime, aerogels can be found in a range of products: Wetsuits, Firefighter Suits, Skylights, Windows, Rockets, Paints, Cosmetics, Nuclear weapons.
Because of aerogel’s unique structure, its use as an insulator a no-brainer. The super-insulating air pockets with the aerogel’s structure almost entirely counteract the three methods of heat transfer: convection, conduction and radiation.
Even though aerogel is still quite expensive, the good news is that studies have shown that aerogel insulation used in wall framing and hard-to-insulate areas such as window flashing can save a homeowner up to $750 per year. In addition to helping homeowners save money, aerogel insulation can significantly reduce your carbon footprint.
Companies are racing to find a way to bring costs down, but for now, aerogels are more affordable for NASA than the general public. Still, aerogels are put to use by construction companies, power plants and refineries.
